G.A.L. Gage Company :: Weld Measuring Pits


Measuring Pit Gauges from G.A.L. Gage Company, like our Weld Measuring Gauges, are the perfect solution for the repeated checking of particular areas. Measuring Pit Gauges make genuine time-savers that you will find indispensible ... and wonder how you ever worked without them.

Measuring Pit Gauges are sturdy, well-made, and come in various handy sizes.

Our Measuring Pit Gauges will surely provide you with many years of service whether in the shop or in the field.


0-1" / 0-25mm Electronic Depth / Pit Gauge
Cat # SPI13-749-7

Electronic Depth / Pit Gauge
Appearance of carrying case may vary

Large LCD - 0.0005" (0.01mm) Resolution, ±0.001" (0.025mm) Accuracy, 0.06" Dia Probes, 2 3/8" Base, Fitted Case & Battery Included, Certificate of Calibration Traceable to NIST, Measurement Scale: Inch / Metric.

$68.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


"V-WAC" Single Weld Gauge
~ Patented ~
Cat # 5

'V-WAC' Single Weld Gauge - Check Undercut, Crown Height, Porosity, Pits, All Stainless Steel
Appearance of carrying case may vary

View Our Product Video

Undercuts/Pits to 1/4 Inch, Crowns to 1/4 Inch by 1/64 Inch Increments (Tolerance 1/64"). Check Undercuts/Pits, Porosity, Crowns, All Stainless Steel.

$36.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


"V-WAC" Single Weld Gauge
Cat # 5d

'V-WAC' Single Weld Gauge - Check Undercut, Crown Height, Porosity, Pits, All Stainless Steel
Appearance of carrying case may vary

View Our Product Video

Undercuts/Pits to 0.240, Crowns to 0.240 by 0.020 Increments. Check Undercuts/Pits, Porosity, Crowns, All Stainless Steel.

$36.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


"V-WAC" Single Weld Gauge
Cat # 5m

'V-WAC' Single Weld Gauge - Check Undercut, Crown Height, Porosity, Pits, All Stainless Steel
Appearance of carrying case may vary

View Our Product Video

Undercuts/Pits to 6mm, Crowns to 6mm by 0.5mm Increments. Check Undercuts/Pits, Porosity, Crowns, All Stainless Steel.

$36.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


Pit Gauge
Cat # 5f

Pit Gauge - Check Undercut/Pits, All Stainless Steel
Appearance of carrying case may vary

Undercuts/Pits to 0-2mm by 0.2mm Increments. Check Undercuts/Pits, All Stainless Steel.

$84.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


Pit Gauge
Cat # 5g

Pit Gauge - Check Undercut/Pits, Crowns, All Stainless Steel
Appearance of carrying case may vary

Undercuts/Pits to 0.08", Crowns to 0.04" by 0.005" Increments. Check Undercuts/Pits, Crowns, All Stainless Steel.

$84.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


Pit Depth Gauge
Cat # 5a

Pit Depth Gauge - Check Undercut, Porosity, Pits, All Stainless Steel
Appearance of carrying case may vary

View Our Product Video

Undercuts/Pits to 1/2 Inch by 1/32 Inch Increments. Check Undercuts/Pits, Porosity, All Stainless Steel.

$59.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


Digital Pit Depth Gauge
Cat # 13DPR

Digital Pit Depth Gauge w/Probes & Rods 1'' - 6''

W/Probes & Rods 1" - 6". Measurement Scale: Reads BOTH Inch & Metric. Probes Included: .025 & .062 Diameter. CR2032 Battery Included. Certificate of Calibration Traceable to NIST.

$325.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


Pipe Pit Gauge
Cat # 17

Pipe Pit Gauge - Range is 0 to 1/2'' in 1/64'' & .010 Increments, Arm Can be Locked in Place at Any Dimension, All Stainless Steel

Range is 0 to 1/2" in 1/64" & .010 Increments, Arm Can be Locked in Place at Any Dimension, All Stainless Steel, Available in Inch or Metric

$86.00

Measurement Scale:



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


Bridge Cam Gauge
Cat # 4

Bridge Cam Gauge

View Our Product Video

The following measurements are possible in either inches or millimeters: Angle of Preparation, Excess Weld Metal, Depth of Undercut, Depth of Pitting, Weld Throat Size, and more.

$126.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


Pocket Bridge Cam Gauge
Cat # 4a

Pocket Bridge Cam Gauge - Check Angle of Preparation, Excess Weld Metal, Depth of Undercut, Depth of Pitting, and more.

Check Angle of Preparation, Excess Weld Metal, Depth of Undercut, Depth of Pitting, and more.

$141.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF
Usage Guide Print-Ready PDF


W.T.P.S. Gauge w/Calibration Block
Cat # 7

WTPS Gauge - Precision made from stainless steel. All markings and dimensions are laser engraved for ease and clarity when reading.
Appearance of carrying case may vary

View Our Product Video

Precision made from stainless steel. All markings and dimensions are laser engraved for ease and clarity when reading.

Gauge set comes with a precision ground calibration block; each block has been surface ground to 0.0005 tolerance for exceptional accuracy.

$66.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


W.T.P.S. Gauge w/Calibration Block
& Mini Maglite® AAA Flashlight

Cat # 7L

WTPS Gauge - Precision made from stainless steel. All markings and dimensions are laser engraved for ease and clarity when reading.
Appearance of carrying case may vary

View Our Product Video

Precision made from stainless steel. All markings and dimensions are laser engraved for ease and clarity when reading.

Gauge set comes with a precision ground calibration block; each block has been surface ground to 0.0005 tolerance for exceptional accuracy.

Set also includes one Mini Maglite® AAA Flashlight (Lumens: 100) w/Pocket Clip, batteries and protective carry case.

$81.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF
