G.A.L. Gage Company :: Weld Measuring Gauges - Adjustable Sizes


Weld Measuring Gauges from G.A.L. Gage Company, permit you to accurately check welds of varying sizes quickly and easily. You can measure Weld Throat Thickness, Butt Fillet Type Welds, Weld Length, Misalignments (High-Low), and much more depending upon the Gauge selected.

Weld Measuring Gauges are sturdy, well-made, and come in numerous types to perfectly fit your requirements.

Our Weld Measuring Gauges will surely provide you with many years of service whether in the shop or in the field.


Economical Electronic Caliper
Cat # SPI30-258-8

SPI30-258-8 Economical Electronic Caliper

An economical 6 inch (150mm) Electronic Caliper for general use. Specifications: Range: 0-6", Resolution: 0.0005", Accuracy: +/- .002", D.O.T. Regulated

$38.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


0-1" / 0-25mm Electronic Depth / Pit Gauge
Cat # SPI13-749-7

Electronic Depth / Pit Gauge
Appearance of carrying case may vary

Large LCD - 0.0005" (0.01mm) Resolution, ±0.001" (0.025mm) Accuracy, 0.06" Dia Probes, 2 3/8" Base, Fitted Case & Battery Included, Certificate of Calibration Traceable to NIST, Measurement Scale: Inch / Metric.

$68.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


Dial Caliper
Cat # SPI17-970-5 (Inch) or # SPI15-804-8 (Metric)

Dial Caliper - 4-way measurement: inside, outside, depth and step

Direct reading: 0.001" / 0.01 mm, Graduations: 0.001" / 0.01 mm, Adjustable bezel w/locking device, Accuracy: +/- 0.001" over 6" travel, 4-way measurements: inside, outside, depth and step; Extra rigid main beam, Easy zero adjustment per revolution, Shock-Proof design, Certificate of calibration traceable to NIST included, Furnished in fitted case.

$61.00

Measure Scale:



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


6" Electronic Caliper - IP54
Cat # SPI18-010-9

6 inch Electronic Caliper - With LCD display, will hold either the zero setting or measured value at any position for differential measurements.

With 1/2" Easy to Read LCD Display

Precision ground hardened stainless steel construction, Inch/Inch fraction/Metric conversion, 4-Way measurements: inside, outside, depth and step, Auto power on/off, With thumb roller and slide lock, Jaw length: 1 19/32", Jaw thickness: 0.136", Display Resolution: 0.0005"/0 - 1/128"/0.01 mm, Accuracy: ±0.001"/±0.02 mm, Furnished in fitted case. Note: D.O.T. Regulated. Shipped via ground freight only.

$60.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


Digital Welding Gauge
Cat # 18

Digital Welding Gauge - With LCD display, will hold either the zero setting or measured value at any position for differential measurements.

With LCD display, will hold either the zero setting or measured value at any position for differential measurements.

$109.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


Combo-Welding Gauge
~ Imported by G.A.L. Gage Company ~
Cat # 20

One side is Inch:
Combo-Welding Gauge - Can Measure in Inch or Metric!

Other side is Metric:
Combo-Welding Gauge - Can Measure in Inch or Metric!

Can Measure in Inch or Metric!
One side is Inch, the other side is Metric

Combo-Welding Gauge - Uses Combo-Welding Gauge - Uses Combo-Welding Gauge - Uses
Combo-Welding Gauge - Uses Combo-Welding Gauge - Uses Combo-Welding Gauge - Uses

The Combo-Welding Gauge can measure in Inch or Metric all of the following:

• Root Size   • Fillet Weld Leg   • Butt Weld Height   • Fillet Weld Throat   • Angle of Preparation

$103.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


Adjustable Fillet Weld Gauge
Cat # 3

Adjustable Fillet Weld Gauge - Unequal Leg Measurement Feature, Measure Fillet Weld & Weld Throat Thickness

View Our Product Video

Unequal Leg Measurement Feature

Measure Fillet Weld & Weld Throat Thickness, Available in Inch or Metric

$90.00

Measurement Scale:



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


Automatic Weld Size Weld Gauge
Cat # 6

Automatic Weld Size Weld Gauge - For Accurate Calibration of Butt Fillet Type Welds

View Our Product Video

For Accurate Calibration of Butt Fillet Type Welds, Available in Inch or Metric

$35.00

Measurement Scale:



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


Bridge Cam Gauge
Cat # 4

Bridge Cam Gauge

View Our Product Video

The following measurements are possible in either inches or millimeters: Angle of Preparation, Excess Weld Metal, Depth of Undercut, Depth of Pitting, Weld Throat Size, and more.

$126.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


Economy Single Purpose Hi-Lo Welding Gauge
~ Imported by G.A.L. Gage Company ~
Cat # 2

Economy Single Purpose Hi-Lo Welding Gauge - 1/32 or Zero Line, Eliminates Rejects - Improves Productivity, Available in Inch or Metric

View Our Product Video

Eliminates Rejects - Improves Productivity, Available in Inch or Metric. Delivered with a protective leather-like carry pouch.

$38.00

Measurement Scale:



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


PRO Single Purpose Hi-Lo Welding Gauge
~ Made in the U.S.A. ~
Cat # 2 PRO

PRO Single Purpose Hi-Lo Welding Gauge - 1/32 or Zero Line, Eliminates Rejects - Improves Productivity, Available in Inch or Metric

View Our Product Video

Eliminates Rejects - Improves Productivity, Available in Inch or Metric.

$49.00

Measurement Scale:



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


HI-LO Welding Gauge
~ Patented ~
Cat # 1

HI-LO Welding Gauge - Measures Internal Alignment, New Slim Design Is 30% Lighter

View Our Product Video

Measures Internal Alignment, New Slim Design Is 30% Lighter

$124.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


"Mini Sub" Socket Weld Gauge
Cat # 14

'Mini Sub' Socket Weld Gauge - Check Throat Dimensions, Leg Length, All Stainless Steel

Check Throat Dimensions, Checks All Pipe Schedule, All Stainless Steel

$98.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


Digital Pit Depth Gauge
Cat # 13DPR

Digital Pit Depth Gauge w/Probes & Rods 1'' - 6''

W/Probes & Rods 1" - 6". Measurement Scale: Reads BOTH Inch & Metric. Probes Included: .025 & .062 Diameter. CR2032 Battery Included. Certificate of Calibration Traceable to NIST.

$325.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


Pit Depth Gauge
Cat # 5a

Pit Depth Gauge - Check Undercut, Porosity, Pits, All Stainless Steel
Appearance of carrying case may vary

View Our Product Video

Undercuts/Pits to 1/2 Inch by 1/32 Inch Increments. Check Undercuts/Pits, Porosity, All Stainless Steel.

$59.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


Pipe Pit Gauge
Cat # 17

Pipe Pit Gauge - Range is 0 to 1/2'' in 1/64'' & .010 Increments, Arm Can be Locked in Place at Any Dimension, All Stainless Steel

Range is 0 to 1/2" in 1/64" & .010 Increments, Arm Can be Locked in Place at Any Dimension, All Stainless Steel, Available in Inch or Metric

$86.00

Measurement Scale:



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


Pocket Bridge Cam Gauge
Cat # 4a

Pocket Bridge Cam Gauge - Check Angle of Preparation, Excess Weld Metal, Depth of Undercut, Depth of Pitting, and more.

Check Angle of Preparation, Excess Weld Metal, Depth of Undercut, Depth of Pitting, and more.

$141.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF
Usage Guide Print-Ready PDF


Skew-T Fillet Weld Gauge
w/ Calculator
Cat # 9c

Skew-T Fillet Weld Gauge INCH - Check Angle of Vertical Member, Weld Acute Side, Weld Obtuse Side

Skew-T Fillet Weld Gauge METRIC - Check Angle of Vertical Member, Weld Acute Side, Weld Obtuse Side

View Our Product Video

Check Angle of Vertical Member, Weld Acute Side, Weld Obtuse Side, Available in Inch or Metric

$135.00

Measurement Scale:



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


"V-WAC" Single Weld Gauge
~ Patented ~
Cat # 5

'V-WAC' Single Weld Gauge - Check Undercut, Crown Height, Porosity, Pits, All Stainless Steel

View Our Product Video

Undercuts/Pits to 1/4 Inch, Crowns to 1/4 Inch by 1/64 Inch Increments (Tolerance .006"). Check Undercuts/Pits, Porosity, Crowns, All Stainless Steel.

$36.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


"V-WAC" Single Weld Gauge
Cat # 5d

'V-WAC' Single Weld Gauge - Check Undercut, Crown Height, Porosity, Pits, All Stainless Steel

View Our Product Video

Undercuts/Pits to 0.240, Crowns to 0.240 by 0.020 Increments. Check Undercuts/Pits, Porosity, Crowns, All Stainless Steel.

$36.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


"V-WAC" Single Weld Gauge
Cat # 5m

'V-WAC' Single Weld Gauge - Check Undercut, Crown Height, Porosity, Pits, All Stainless Steel
Appearance of carrying case may vary

View Our Product Video

Undercuts/Pits to 6mm, Crowns to 6mm by 0.5mm Increments. Check Undercuts/Pits, Porosity, Crowns, All Stainless Steel.

$36.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


Pit Gauge
Cat # 5f

Pit Gauge - Check Undercut/Pits, All Stainless Steel
Appearance of carrying case may vary

Undercuts/Pits to 0-2mm by 0.2mm Increments. Check Undercuts/Pits, All Stainless Steel.

$84.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


Pit Gauge
Cat # 5g

Pit Gauge - Check Undercut/Pits, Crowns, All Stainless Steel
Appearance of carrying case may vary

Undercuts/Pits to 0.08", Crowns to 0.04" by 0.005" Increments. Check Undercuts/Pits, Crowns, All Stainless Steel.

$84.00



Please allow 4-6 days for delivery.


Detailed Specifications Print-Ready PDF


For Delivery Outside the United States:

Delivery Outside the United StatesIf your order is to be delivered to a location outside the United States, we generally must add 10% to cover the additional Shipping & Handling charges. However, depending upon your items ordered and delivery location, this additional 10% might be too high or too low.

Please contact us with your list of desired items and delivery location so we may quote this adjusted total more accurately:
